OPTIMUM
MASCHINEN - GERMANY
Version 3.1.8 dated 2015-1-27Page 50 Original operating instructions
BF20VUS
8 Appendix
8.1 Copyright
This document is copyright. All derived rights are also reserved, especially those of translation,
re-printing, use of figures, broadcast, reproduction by photo-mechanical or similar means and
recording in data processing systems, neither partial nor total.
Subject to technical changes without notice.
8.2 Terminology/Glossary
8.3 RoHS , 2002/95/CE
The sign on the product or on its packing indicates that this product complies with the European
guideline 2002/95/EC .
Term Explanation
Cross table Bearing surface, clamping surface for the workpiece with X- and Y-
axis travel
Taper mandrel Cone of the drill or of the drill chuck
Draw-in rod Threaded rod to fix the taper mandrel in the spindle sleeve.
Drill chuck Device for holding the bit
Collet chuck Holder for end mill
Drilling and milling head Upper part of the mill drill
Spindle sleeve Hollow shaft in which the milling spindle turns.
Milling spindle Shaft activated by the motor
Drilling table Supporting surface, clamping surface
Taper mandrel Cone of the drill or of the drill chuck
Spindle quill lever Manual operation for the drill feed
Quick action - drill chuck Drill chuck can be fixed by hand.
Workpiece Piece to be drilled or machined.
Tool Milling cutter, drill bit, etc.
