OPTIMUM
MASCHINEN - GERMANY
Version 3.1.8 2015-1-27 45Original operating instructions
BF20V US
6.8.1 Spare part list
Pos.
Description Qty. Drawing no. Size Article no.
1 Connect board 1 DM14-01-14 0333812001
2 Socket head set screw 2 GB 79-85 M6 x 16
4 Spring washer 6 GB 93-87 M8
5 Hexagon head cap screw 2 ISO 4762 M8 x 25
6 Hexagon head screw 1 GB 5783-86 M12 x 40
7 Spring washer 5 GB 93-87 M12
8 Washer 1 DM14-01-39 0333812008
9 Screw 1 0333812009
10 Washer 1 DM14-01-40 0333812010
11 Spring washer 1 GB 93-87 M10
12 Hexagon nut 1 GB 6170-86 M10
13 Connect collar 1 DM14-01-13 0333812013
14 Brass pin 6 DM14-00-05 0333812014
15 Adjust locating handle 4 JBT 7270.12-1994 DM6 x 16 0333812015
16 Gib screw 6 DM14-02-20 0333812016
17 Taper gib z axis 1 DM14-00-01 0333812017
18 Angle plate 1 DM14-00-03 0333812018
19 Hexagon head cap screw 20 GB 70-85 M5 x 10
20 Bellows 1 DM14-00-06 0333812020
21 Hexagon nut 2 DIN EN 24 032 M5
22 Bellows bracket 1 DM14-00-06 0333812022
23 Rubber splash guard 1 DM14-00-08 0333812023
24 Plate 1 DM14-00-09 0333812024
25 Groove nut 2 GB 810-88 M16x1.5 0333812025
26 Axially grooved ball bearing 1 51203 51203 04051203
27 Taper gear 1 DM14-03-06 26 Z ; m 1,5 0333812027
28 Key 3 DIN 6885 A 4 x 4 x 16 0333812028
29 Lift lead screw 1 DM14-03-04 0333812029y
30 Lift lead screw nut 1 DM14-03-05 0333812030y
31 Washer 8 GB 97.1-85 5
32 Nut collar 1 DM14-03-01 0333812032
33 Hexagon head cap screw 4 GB 70-85 M8 x 20
34 Column cover 1 DM14-03-02 alt / old 0320218
35 Bearing cover 1 DM14-03-10 0333812035
37 Lift dial z axis 1 DM14-03-11 0333812037y
38 Spring piece 4 0333812038
39 Handwheel z axis 1 DM14-03-13 0333812039
40 Hexagon nut 4 ISO 4033 M8
41 Handle complete 1 0333812041
41-1 Handle sleeve 1 JB7270.5-1994-80 80 0333812041-1
41-2 Screw 1 JB7270.5-1994-M10 M10 x 80 0333812041-2
42 Grooved ball bearing single-row 2 6001-2RZ 0406001.2R
43 Lift shaft z axis 1 DM14-03-12 0333812043
44 Key 5 DIN 6885 A 4 x 4 x 12 0333812044
45 Lift bearing base 1 DM14-03-09 0333812045
46 Collar 1 DM14-03-08 0333812046
47 Taper gear 1 DM14-03-07 0333812047
48 Column 1 DM14-03-03 0333812048
49 Scale (inch) 1 DM14-00-04 0333812049y
50 Cylindrical pin 4 GB 119-86 A 5 x 24
51 Hexagon head cap screw 11 GB 70-85 M6 x 16
52 Table dial support x axis left 1 DM14-02-02 alt / old 0320232
54 Cross table 1 DM14-02-03 BF20 0333812054
54 Cross table 1 DM14-02-03L BF20 L 0333812254
55
Screwing in screw connection hose
connector
1 DM14-02-18 M10 x 1 0333812055
56 Table dial support x axis 1 DM14-02-06 alt / old 0320235
57 Handle complete 3 0333812057
57-1 Handle sleeve 3 JB7270.5-1994-63 63 0333812057-1
57-2 Screw 3 JB7270.5-1994-M8 M8 x 63 0333812057-2
58 Handwheel cross table 3 DM14-02-01 0333812058
59 Dial 3 DM14-02-19 0333812059y
60 Axially grooved ball bearing 5 51200 alt / old 04051200
61 Hexagon head cap screw 2 GB 70-85 M6 x 10
62 Stopper x axis 2 DM14-02-04 0333812062
63 Wedgy nut 2 DM14-02-05 0333812063
64 Table plate x axisBF20 1 DM14-00-02 BF20 0333812064y
65 Table lead screw x axis BF20 1 DM14-02-11 BF20 0333812065y
