OPTIMUM
MASCHINEN - GERMANY
Version 3.1.8 2015-1-27 46 Original operating instructions
BF20VUS
66 Table lead screw nut x axis 1 DM14-02-09 0333812066y
67 Hexagon head cap screw 4 GB 70-85 M4 x 20
68 Saddle 1 DM14-02-08 BF20 0333812068
69 Limit plate x axis 1 DM14-02-07 0333812069
70 Taper gib y axis 1 DM14-02-10 0333812070
71 Lead screw nut y axis 1 DM14-02-16 0333812071y
72 Taper gib x axis 1 DM14-02-17 BF20 0333812072
73 Hexagon head cap screw 2 GB 70-85 M6 x 25
74 Saddle dial support 1 DM14-02-13 0320249
75 Lead screw y axis 1 DM14-02-14 0333812075y
76 Base 1 DM14-02-15 BF20 0333812076
77 Hexagon head cap screw 4 GB 70-85 M12 x 90
78 Clamping lever 4 JBT7270.12-1994 DM6x16 0333812078
78 Spacer ring for spindle z axis 1 DM14-03-15 0333812078
79 Case for z axis 1 DM14-03-14 0333812079
80 Washer 6 GB 97.1-85 8
81 Washer 2 GB 97.1-85 4
83 Hexagon head cap screw 6 GB 70-85 M6 x 12
90 Machine lightning complete 1 0333812090
90-1 Housing machine lightning 1 0333812090-1
90-2 Protection glas 1 0333812090-2
90-3 Cover machine lightning 1 0333812090-3
H 1.5
Halogen lamp
12V , 10 W, Sockel G4
1 03338120H15
91 6 GB 97.1-85 3
98 Countersunk screw 1 BS 4183 M5 x 12
112 Holder screw rod 1 DM14-01-42 03338120112
114 Draw bar 1 DM14-20-02 3/8"-16 03338120114y
117 Clamping screw collar 1 DM14-01-43 03338120117
119 Endplate 1 DM14-01-25 03338120119
126 Protection device complete 1 BF20-XHZMX 03338120126
126-1 Housing 1 BF20-XHZMX 03338120126-1
126-2 Aluminium profile admission 1 BF20-XHZMX 03338120126-2
126-3 Clamping scew 1 BF20-XHZMX 03338120126-3
126-4 Aluminium profile 1 B15-04-02 L=290mm 03338120126-4
126-5 Protection 1 BF20-XHZMX 03338120126-5
126-6 Screw 2 BF20-XHZMX 03338120126-6
126-7 Steel ball 1 BF20-XHZMX 03338120126-7
126-8 Spring plate 1 BF20-XHZMX 03338120126-8
126-9 Screw 2 BF20-XHZMX 03338120126-9
126-10 Micro switch spindle protection 1 BF20-XHZMX 03338120126-10
126-11 Cover 1 BF20-XHZMX 03338120126-11
127
Hexagon head cap thread pin screw
with point
1 GB 78-85 M5 x 6 03338120127
137 Scale-pin 1 03338120137
139 Stopper 1 DM14-00-10 03338120139
140
Hexagon head cap thread pin screw
with flat end
1 GB 77-85 M6 x 20
141 Hexagon nut 1 GB 6170-86 M6
160 Cheese head screw 2 ISO 7045 M3 x 6 - 4.8 - H
164-3 Housing control boards 1 DM14-10-04 03338120164-3
165-1 Panel housing 1 DM14-10-02A 03338120165-1
165-2 Cover 1 DM14-10-01A 03338120165-2
165-3 Cover 1 03338120165-3
165-12 Innensechskantschraube 4 GB 70-85 M4 x 30
166 Label loose / tighten 1 03338120166
167 Label Micro feed 1 03338120167
168 Morse taper MK2 - B16 1 DM14-MS2W-B16 03338120168
169 Mounting plate panel 1 DM14-10-07 03338120169
170 Mounting plate panel 1 DM14-10-08 03338120170
171
Innensechskant-Gewindestift with cup
point
1 GB 80-85 M5 x 12 03338120171
172 Holding arm panel 1 DM14-10-06 03338120172
173 Hexagon head cap screw 4 GB 70-85 M4 x 6
201 Position washer 1 DM14-01-08 03338120201
202 Spring sleeve 1 DM14-01-07 03338120202
203 Spring 1 GB2089-94 2.5x28x110-3 03338120203
204 Retainer ring 1 GB 894.1 - 45 03338120204
205 Grooved ball bearing 1 6209-2Z 6209-2Z 0406209.2R
206 Gear combination 1 DM14-01-06
Z 60 / Z 80, m
1
03338120206
Pos.
Description Qty. Drawing no. Size Article no.
