OPTIMUM
MASCHINEN - GERMANY
Version 3.1.8 2015-1-27 47Original operating instructions
BF20V US
207 Grooved ball bearing 1 6007-2Z 6007-2Z 0406007.2R
208 Retainer ring 1 DIN 471 15 x 1 03338120208
209 Gear diagonally-toothed 1 DM14-01-10
Z 37, m 1,25,
9°
03338120209
210 Retainer ring 2 DIN 472 32 x 1.2 03338120210
211 Grooved ball bearing 2 6002-2Z 6002-2Z 0406002.2R
212 Gear combination 1 DM14-01-05
Z 62 / Z 42, m
1
03338120212
213 Intermediate shaft 1 DM14-01-04 03338120213
214 Key 1 DIN 6885 A 5 x 5 x 50 03338120214
215 Key 1 DIN 6885 A 5 x 5 x 12 03338120215
216 Fork 1 DM14-01-17 03338120216
217 Fork arm 1 DM14-01-16 03338120217
219 Cover 1 DM14-01-09 03338120219
220 Motor cover 1 DM14-01-35A 03338120220
222 Hexagon head cap screw 4 GB 70-85 M4 x 8
223 Washer 8 GB 848-85 4
224 Hexagon head cap screw 6 GB 70-85 M6 x 20
226 Spring washer 6 GB 93-87 M6
227 Fixed cover 1 DM14-01-20 03338120227
229 Retainer ring 1 GB 894.1 10
230 Gear diagonally-toothed 1 DM14-01-11
Z 20, m 1,25,
9°
03338120230
233 Hexagon head cap screw 2 GB 70-85 M3 x 20
234 Digital slide guage 1 DQ1 03338120234
234-1 Prodective cover 1 03338120235
235 Base for ruler digital display 1 DM14-01-31 03338120237
237 Clamping and guide pin 1 DM14-01-34 03338120238
238 Housing milling head 1 DM14-01-19 03338120239
239 Cover 1 DM14-01-12
240 Countersunk screw 6 GB 819-85 M4x8
241 Micro feed knob 1 DM14-01-30 03338120241
242
Hexagon head cap thread pin screw
with point
1 GB 78-85 M5 x 6
243 Spring piece 1 03338120243
244 Micro feed dial 1 DM14-01-28 03338120244y
245 Worm shaft 1 DM14-01-27 03338120245
246 Spindle 1 DM14-01-03 03338120246
247 Nut 1 DM14-01-01 03338120247
248 Taper roller bearing single-row 2 32005 X/Q 04032005
249 Collar 1 DM14-01-02 03338120249
250 O-ring 1 GB 3452-1 58x2.65 03338120250
251 Clamp nut 1 DM14-01-41 03338120251
252 Cylindrical pin 4 GB 119-86 B4x20
253 Thread pin slit with long tap 4 GB 79-85 M5 x 12
254 Cylindrical pin 1 GB 120-86-A 6x30
255 Handle complete 3 03338120255
255-1 Threaded rod 3 JB_T7271.6-1994 BM10x80 03338120255-1
255-2 Handle 3 JBT7271.5-1994 03338120255-2
256 Locking knob 1 DM14-01-21 03338120256
257 Feed handle disc 1 DM14-01-22 03338120257
258 Feed dial 1 DM14-01-36 03338120258y
259 Compression spring 1 GB2089-94 1.2x12x25-3 03338120259
260 Hexagon head cap screw 3 GB 70-85 M4 x 10
261 Cover 1 DM14-01-26 03338120261
262 Adjust collar 1 DM14-01-37 03338120262
263 Clutch with gear 1 DM14-01-23 03338120263
264 Key 1 DIN 6885 A 4 x 4 x 12 03338120264
265 Toothed shaft 1 DM14-01-24 03338120265
266 Thread pin slit with long tap 1 GB 79-85 M6 x 20
267 Plate 1 DM14-BP-03 03338120267
268
Hexagon head cap thread pin screw
with flat end
1 GB 77-85 M8 x 8
269 Compression Spring 1 GBT2089-94 0.8x5x25-3 03338120269
270 Steel ball 1 GBT308-1994 6,5 03338120270
271 Locating knob 1 DM14-01-33 03338120271
272
Hexagon head cap thread pin screw
with point
2 GB 78-85 M5 x 8
273 Shifting plate 1 DM14 03338120273
274 Locating base 1 DM14-01-38 03338120274
275 Shifting shaft 1 DM14-01-15 03338120275
Pos.
Description Qty. Drawing no. Size Article no.
