Version 3.1.8 2015-1-27 48 Original operating instructions
BF20VUS
276 Hexagon head cap srew 6 GB 70-85 M3 x 6
277 Angle sensor 1 03338120277
278 Hexagon head cap screw 2 GB 70-85 M5 x 8
279 Sensor, number of revolutions 1 03338120279
280 Optional sub structure 1 03338120280
281 Optional pan sub structure 1 03338120281
282 Washer 4 GB 848-85 10
283 Hexagon head screw 4 GB 5783-86 M10 x 30
284 Strain relief connection cable 1 03338120284
285 Lubrication catch 1 03338120285
286 Table dial support x axis left 2 DM14-02-02-A 03338120286
287 Grooved ball bearing, single-row 1 6000 0406000.2R
288 Snap ring 1 DIN 472 28 x 1,2 03338120288
289 Distance case 1 03338120289
290 Distance case 1 03338120290
291 Table dial support x axis 1 DM14-02-06-A 03338120291
292 Skew-angle roller bearing, double-row 1 3203 0403203
293 Column cover 1 DM14-03-02-A 03338120293
294 Skew-angle roller bearing, double-row 2 3200 0403200
295 Saddle dial support 1 DM14-02-13-A 03338120295
296 Sensor ring 1 03338120296
299 Distance case 1 03338120299
300
Start- Stop connection for CNC cont-
roller
1 03338120300
301 Knob 1 03338120301
302 Plastic plate 1 03338120302
303 Plug 2 03338120303
304 Plug 1 03338120304
S1.1 Main switch 1 03338120S1.1
S1.2 Emergency push button 1 03338120S1.2
S1.3 On- Off push button 1 03338120S1.3
S1.4 On- Off switch halogen lamp 1 03338120S14
S1.5 Change over switch ZH-A 1 03338120996
S1.6 Micro switch spindle protection 1 0333812012610
R1.5 Potentiometer 4,7 K
V 1 0320298
T1.4 Transformer 230V / 12V 1 03338120T1.4
P1.3 Digital speed indicator 1 03338120P1.3
Q 1.6 Control board 1 JYMC-220B-II 03338128Q1.6
Q1.7 Relay board 1 115V 03338128Q1.7
H 1.5
Halogen lamp
12V , 10 W, socket G4
1 03338120H15
M Motor 1 110V DC 03338128221
M - 1 Carbon brush motor 2 03338120994
X1 Cable 1 03338120998
F1/
F1.2
Fuse 2 10A 03338120F1y
LF1 Line filter 1 03338120LF1
LF2 Line filter 1 03338120LF2
Pos.
Description Qty. Drawing no. Size Article no.
