Assembly
OPTIMUM
MASCHINEN - GERMANY
30 / 11 / 2007Page 32 Assembly Add-on kit D240/D280 ; Version 1.3.3
© 2007
GB
£ Plug the lathe chuck protection to
the support again and tighten it with
the safety screw.
Illustr.: 4-69: Lathe chuck protection
£ Disassemble the handle of the hand-
wheel of the lathe slide.
CAUTION!
Danger due to rotating parts.
Illustr.: 4-70: Disassembly handle
Lathe chuck protec-
tion
Handle handwheel
lathe slide
Screw driver
