Wiring of step motors on the machine
30 / 11 / 2007 Page 35Wiring of step motors on the machine Add-on kit D240/D280 ; Version 1.3.3
© 2007
GB
INFORMATION!
If the turning direction of one - or several step motors with CNC operation via a CNC
software is being wrong, please exchange the corresponding connection on the step
motor or on the CNC controller.
Example:
Motor Controller
A- to B-
A+ to B+
B- to A-
B+ to A+
GND
