Version 1.0.1 - 2020-07-23 13Translation of original instruction
B20 | B25 | B32 EN
B20-B25-B32_GB.fm
1.11 Emergency stop button
ATTENTION!
The drilling spindle keeps turning for a short time even after actuating the emergency
stop push button depending on the preset speed.
1.12 Drill chuck guard
INFORMATION
The machine cannot be started, if the drill chuck guard is not closed.
Adjust the guard to the correct height before you start working.
To do so, slacken the clamping screw, set the required height and re-tighten the clamping
screw.
There is a switch integrated in the spindle protection mounting which monitors the closed posi-
tion.
