Version 1.0.1 - 2020-07-2326 Translation of original instruction
B20 | B25 | B32
EN
B20-B25-B32_GB.fm
Img.3-10: Stand
ATTENTION!
Tighten the fixing screws of the drilling machine only as much that it is safely fixed and
cannot break away or tilt over.
If the fixing screws are too tight in particular in connection with an uneven substructure
it may result in a broken stand of the machine.
3.6.2 Installation diagrams B25, B32
3.7 First commissioning
WARNING!
Risk from using improper workpiece clamping materials or operating the machine at an
inadmissible speed.
Only use the tool holders (e.g. drill chuck) which were delivered with the machine or
which are offered as optional equipment by OPTIMUM.
Only use tool holders in the intended admissible speed range.
Tool holders may only be modified in compliance with the recommendation of OPTIMUM
or of the manufacturer of the clamping devices.
