Version 1.0.1 - 2020-7-23 51Originalbetriebsanleitung
B20 | B25 | B32 de | en
B20-B32_parts.fm
41 Motor Motor 1 230 V 0300820141
41 Motor Motor 1 400 V 0300820341
41-1 Motorlüfter Motor Fan 1 03008203411
42 Federscheibe Lock washer 4 8
43 Mutter nut 4 M 8
44 Mutter nut 2 M 10
45 Scheibe Washer 2 10
46 Gleitstange Rod 1 0300820146
47 Schraube Screw 1 M 6x12
48 Excenter Eccentric 1 0300820148
49 Schaltergehäuse Switch housing 1 230 V 0300820149
49 Schaltergehäuse Switch housing 1 400 V 0300820349
51 Bleichschraube Screw 1
52 Schalter Switch 1 230 V 0300820152
52 Schalter Switch 1 400 V 0300820352
53 Anschlusskabel Power Wire 1 230V 0342025107
53 Anschlusskabel Power Wire 1 400V 0300825353
55 Bolzen Bolt 1 M 6x10
56 Scheibe Washer 4 6
58 Riemenscheibe Motor Motor pulley 1 0300820158
58-1 Passfeder Fitting key 1 042P5540
59 Madenschraube Grub screw 1 M 5 x 6
60 Sicherungsring Retaining ring 1 35 042SR35I
61 Kugellager Bearing 2 6201 0406201R
62 Keilriemen V-belt 1 10 x 610 0300820162
63 Riemenscheibe Mitte Middle Pulley 1 0300820163
64 Zentrierteil Centering Device 1 0300820164
66 Riemenabdeckung Pulley Cover 1 0300820166
67 Keilriemen V-belt 1 10 x 605 0300820167
68 Rundmutter Round Nut 1 0300820168
69 Spindelriemenscheibe Spindle pulley 1 0300820169
70 Mitnehmer Actuator 1 0300820170
71 Sicherungsring Retaining ring 1 47 042SR47I
72 Kugellager Bearing 1 6005 0406005R
73 Distanzscheibe Collet 1 0300820173
76 Sicherungsring Retaining ring 1 15 042SR15W
77 Kugellager Bearing 1 6005 0406005R
78 O-Ring O-Ring 1 B25 , B20 0300820178
79 Pinole Pinole 1 0300820179
80 Austreiber Drill Drift 1 0300816174
81 Kugellager Bearing 1 6205 0406205R
82 Spindel B20 Spindle B20 1 MT2 0300820182
82 Spindel B25 Spindle B25 1 MT3 0300825382
85 Bohrfutterschutz alter typ
Drill chuck protection old
type
1 B20 , B25
3008205 + 3008206 +
3008207 + 3008206
86 Ring für Kabelschutz Ring for Protecting Wire 1
87 Mutter Nut 1
