OPTIMUM
MASCHINEN - GERMANY
2012
Maintenance
Version 1.0.1 dated 30 / 08 / 2012
Page 35
Original operating instructions
MH28V
GB
5.1.1 Preparation
WARNING!
Only carry out work on the drilling-milling machine if it has been disconnected from
the mains power supply.
“Disconnecting and securing the drilling-milling machine“ on page 14
Position a warning sign.
5.1.2 Restarting
Before restarting, run a safety check.
“Safety check“ on page 13
WARNING!
Before starting the drilling-milling machine you have to check that there is no danger
for the staff and the drilling-milling machine is undamaged.
5.2 Inspection and maintenance
The type and extent of wear depends to a large extent on individual usage and service con-
ditions. For this reason, all the intervals are only valid for the authorised conditions.
Interval Where? What? How?
Start of work,
after each
maintenance
or repair oper-
ation
Drilling-Milling machine
“Safety check“ on page 13
Start of work,
after each
maintenance
or repair oper-
ation
Dovetail slideways
Lubricate
Lubricate all slideways.
Weekly
Cross table
Lubricate
Lubricate all blank steel parts. Use acid-free oil, for
example weapon oil or engine oil.
As required
Spindle nuts
Readjust
An increased clearance in the spindles of the crosstable can be
reduced by readjusting the spindle nuts. Refer to spindle nuts posi-
tion 66 and 71
The spindle nuts are readjusted by reducing the flank of screw
thread of the spindle nut with an adjusting screw. By readjusting a
smooth running move over the whole toolpath is to be assured, oth-
erwise the wear by friction between spindle nut /spindle would
increase considerably.
