Optoma EP776 - Table of Contents

EP776 Series/EP782 Series
Condential
Table of Content
Chapter 1 Introduction
Highlight 1-1
Compatible Mode 1-3
Chapter 2 Disassembly Process
Equipment Needed & Product Overview 2-1
Disassemble Lamp Cover Module 2-2
Disassemble Lamp Module 2-2
Disassemble Top Cover Module 2-3
Disassemble Front Ring Module 2-4
Disassemble Keypad Module 2-4
Disassemble IR Sensor Module 2-5
Disassemble Rear Cover Module 2-6
Disassemble Top Shielding & Wireless Module 2-6
Disassemble Main Board Module 2-7
Disassemble Network Module 2-8
Disassemble IO Board Module 2-8
Disassemble Fan Module 2-9
Disassemble LVPS Module 2-10
Disassemble Engine Module 2-11
Disassemble Color Wheel Module 2-13
Disassemble DMD Board & DMD Chip Module 2-14
Disassemble Zoom Ring & Zoom Ring Base & Focus Ring 2-15
Disassemble Rod Module 2-16
Disassemble Duct Module 2-16
Disassemble Blower Module 2-17
