Optoma EP776 - Page 77

EP776 Series/EP782 Series
Condential II
Item P/N Rev Description Parts Supply
1 51.87Y20G001 A ROD BLOWER DUCT PPS-AR04B
P7270I
NO
2 61.83J14G001 A HEX SPACER M3-3.0 W5 L20.0 COP-
PER PD527
NO
3 61.89532G001 A HEX SPACER H29 4100MP NO
4 61.87340G001 A STAND OFF M3*4L D8.0 2100MP NO
5 61.88E01G001 A 280W OSARM LAMPDRIVER BRAC-
KET
NO
6 49.87C01G001 A SUNON 6025 BLOWER
7 70.87Y08G001 A SUB ASSY ROD BLOWER MODULE
P7270I
NO
8 75.88B13G001 B ASSY BOTTOM COVER MODULE
EP782
9 70.88B09G001 A ASSY WIND TUNNEL MODULE EP782 NO
10 75.88B03G001 A BUY ASSY LIMIT SWITCH MODULE E
11 75.87Y05G001 A ASSY INTERRUPT SWITCH MODULE
P
12 49.87Y01G001 A DELTA 105X32 SYSTEM AXIAL FAN
70.88E20GR01 A OSRAM 280W LAMP DRIVER FOR
EP776 (SERVICE)
13 70.88E02G001 A ASSY LAMP DRIVER MODULE EP776 NO
14 85.1A123G060 A SCREW PAN MECH M3*6 NI NO
15 85.1A126G040 A SCREW PAN MECH M2.6*4 Ni NO
16 85.3A522G040 A SCREW CAP MECH M2*4-D8 NI NO
