36
User Controls
N
ote
N
ote
Each I/O has
di󰘯erent setting of
“Edge Mask”.
When anamorphic lens is 󰘰xed
16:9 Screen 480i/p 576i/p 1080i/p 720p PC
4:3 1080 x 1080 center
16:9 1440 x 1080 center
LBX
(#1)
Catch
720 x 363
(Center)
Catch
720 x 436
(Center)
Catch
1920 x 817
(Center)
Catch
1920 x 545
(Center)
Catch
75.65%
of height
(Center)
Scale to 1920 x 1440, then get the central 1920 x 1080
image to display
Auto235
(#1)
(same button
on remote of
Native)
When source is 2.35:1(with black bar at top/bottom), Doing
LBX format.
When source isn’t 2.35:1 that is full 4 x 3 or 16 x 9 (There is
no black bar at top/bottom), doing 16 x 9 format
Auto235_
Subtitle
Catch
720 x 422
(bottom)
Catch
720 x 506
(bottom)
Catch
1920 x 948
(bottom)
Catch
1920 x 632
(bottom)
Catch
87.8%
of height
(bottom)
When source is 2.35:1(with black bar at top/bottom), Doing
above catching rule and Scale to 1920 x 1440, then get the
central 1920 x 1080 image to display.
When source isn’t 2.35:1 that is full size 4 x 3 or 16 x 9
(There is no black bar at top/bottom), doing 16 x 9 format
Edge Mask
Edge Mask the image to remove video encoding noise on
the edge of video source.
Zoom

Press ◄ to reduce the size of the image.

Press ► to magnify an image on the projected screen.
