Optoma PK201 - Table of Contents

PK201
Condential
II
Table of Content
Chapter 1 Introduction
Highlight 1-1
Compatible Mode 1-2
Chapter 2 Disassembly Process
Equipment Needed & Product Overview 2-1
Disassemble Battery Cover Module 2-2
Disassemble Top Cover Module 2-2
Disassemble Key Pad Module 2-3
Disassemble IR Cover and Speaker Holder 2-4
Disassemble Engine Module and Main Board Module 2-4
Disassemble the Focus Ring and Focus Gear 2-6
Chapter 3 Troubleshooting
Equipment Needed 3-1
Main Procedure 3-2
Power Troubleshooting 3-3
Image Performance Troubleshooting 3-4
Audio Troubleshooting 3-7
Chapter 4 Function Test & Alignment Procedure
Test Equipment Needed 4-1
Service Mode 4-1
System Reset 4-1
Test Condition 4-2
Test Inspection Procedure 4-3
PC Mode 4-4
