Optoma W402 - Input;Output Connections

9
English
Introduction
Input/Output Connections
15
6
11
15
10
15
6
11
15
10
Video connector1.
3D Sync Out (5V) connector2.
RJ-45 connector3.
VGA Out connector4.
VGA2 In / YPbPr connector5.
VGA1 In / YPbPr / 6. connector
Power Socket7.
USB-B mini connector (Firmware upgrade)8.
HDMI connector9.
RS-232C connector10.
Audio1 In connector11.
Audio Out connector12.
Audio2 In connector13.
Security Bar14.
Remote mouse 
requires special
remote.
8 791011121314
5 62 41 3
