Opus T2 User Manual

18
Specifications
General
Frequency Range
PRO version: 403~470MHz
446 version: 446.00625~446.09375MHz
Channel Capacity
16 Channels
Channel Bandwidth
12.5kHz
Operating Voltage
7.4V DC
Dimensions (H x W x D)
130 x 53 x 32mm exc. antenna
Weight (with battery)
240g
Transmitter
RF Output power
PRO version: 4W/1W (High/Low)
446 version: 500mW
Frequency Stability
±1.5ppm
Spurious & Harmonics
-36dBm for f <1GHz,
-30dBm for f > 1GHz
FM Hum & Noise
45dB
Modulation Deviation
±2.5kHz
Adjacent Channel Power
70dB
Audio Frequency Response
+1 ~ -3dB (0.3 – 3kHz)
Audio Distortion
< 3%
Receiver
Sensitivity (12 dB SINAD)
-122dBm (0.18μV)
Adjacent Channel Selectivity
70dB
Audio Distortion
< 5%
Radiated Spurious Emissions
< -54dBm
Intermodulation Rejection
70dB
Audio Output (8 Ω load)
750mW typ. (< 3% distortion)
All specifications are subject to change without notice.

Opus T2 Specifications

General

Brand	Opus
Model	T2
Category	Two-Way Radio
Language	English
