Dimensions and Weights
Installation Planning 2-3
Shipping Weights and Dimensions
The SL8500 library is delivered on pallets that can measure up to 2.5 m (8.25 ft) in
length and weigh up to 481 kg (1060 lb). Ensure there are forklifts or pallet jacks that
can handle these pallets. If moving between floors, verify the elevator can handle these
loads.
Total Pallet Weights
The total weight of the pallets for various library configurations are listed below. If
ordering the optional CAP, increase the total weight by 33 kg (73 lb). CAPs are shipped
on their own pallet. Similarly, if ordering redundant robotics, increase the total weight
by 65 kg (143 lb). Four additional robots are shipped on an additional #10 pallet.
Additional pallets not listed below may be shipped depending on the library features
ordered.
Shipping Pallets Weights and Dimensions
The individual pallet sizes and weights are listed below:
Table 2–3 Tape Drive and Cartridge Weights
Drive Type Tape Drive Weight (with drive tray) Cartridge Tape Weight
T9840 8.2 kg (18.0 lb) 262 g (9.2 oz)
T9940 11 kg (24.3 lb) 262 g (9.2 oz)
T10000 9.4 kg (20.75 lb) 264 g (9.31 oz)
LTO 6.9 kg (15 lb) 210 g (7.4 oz)
SDLT 6.7 kg (14.8 lb) 222.5 g (7.85 oz)
Note: The values listed are estimates and subject to change. The
values are for a bulk CAP library.
Table 2–4 Total Pallet Weights for a Selected Library Configuration
Configuration Pallets Shipped
Approximate Total
Weight
Basic Library 1, 2, 3, 4, 5, 6, 7, 8, 9, 9A, 10 2481 kg (5,470 lb)
One SEM 1, 2, 3, 4, 4A, 5, 6, 7A, 8, 8A, 9, 9A, 10 3090 kg (6,814 lb)
Two SEMs 1, 2, 3, 4, 4A (x2), 5, 6, 7B, 8, 8A (x2), 9, 9A, 10 3709 kg (8,178 lb)
Three SEMs 1, 2, 3, 4, 4A (x3), 5, 6, 7C, 8, 8A (x3), 9, 9A, 10 4336 kg (9,562lb)
Four SEMs 1, 2, 3, 4, 4A (x4), 5, 6, 7D, 8, 8A (x4), 9, 9A, 10 4887 kg (10,777 lb)
Five SEMs 1, 2, 3, 4, 4a (x5), 5, 6, 7E, 8, 8A (x5), 9, 9A, 10 5436 kg (11,987 lb)
Table 2–5 Shipping Pallets –Weights and Dimensions
Pallet Description Height Width Length Weight
1 Lower DEM 205 cm (81 in.) 97 cm (38 in.) 185 cm (73 in.) 480 kg (1058 lb)
2 Upper DEM 87 cm (34 in.) 97 cm (38 in.) 185 cm (73 in.) 160 kg (353 lb)
3 Lower RIM 198 cm (78 in.) 99 cm (39 in.) 183 cm (72 cm) 293 kg (646 lb)
4 Upper RIM 94 cm (37 in.) 94 cm (37 in.) 188 cm (74 in.) 113 kg (249 lb)
4A SEM - Frame (one per SEM) 120 cm (47 in.) 105 cm (41 in.) 244 cm (96 in.) 357 kg (787 lb)
5 CIM 120 cm (47 in.) 82 cm (32 in.) 244 cm (96 in.) 332 kg (732 lb)
6 Z-frame 76 cm (30 in.) 66 cm (26 in.) 246 cm (97 in.) 136 kg (300 lb)
