See also:
■
“Locations of Internal Server Components” on page 30
■
“Front Panel System Status LEDs” on page 78
Next:“Rear Panel Features and Components” on page 16
Rear Panel Features and Components
Legend
1 AC power connector 2 White Locate LED
3 Amber Service Action Required LED 4 Green Power Status LED
5 Serial Management (SER MGT) port (RJ-45) 6 GigabitEthernet port (NET-0)
7 GigabitEthernet port (NET-1) 8 USB 2.0 ports (2)
9 Network Management (NET MGT)
Ethernet port (available only in systems with
an SP module)
10 HD-15 video connector (available only in systems
with an SP module)
11 PCIe slot (Gen 2, x16)
See also:
■
“Locations of Internal Server Components” on page 30
■
“Rear Panel System Status LEDs” on page 80
■
“Front Panel Features and Components” on page 15
Rear Panel Features and Components
Sun Fire X2270 M2 Server Service Manual • January, 2012, –1216
