Press and release the recessed power button on the server front panel.
Note – If necessary, use a stylus or other nonconducting pointed object to depress the power on
button.
The server performs power-on self tests (POST) and boots to the OS.
“How to Power O the Server” on page 28
Component Replacement Procedures and Topic
The procedures in this section are separated into customer-replaceable units (CRUs) and eld
replaceable units (FRUs). For more information about CRUs and FRUs, see
“CRU and FRU
List” on page 19
.
Component Designations Procedures andTopics
Component locations “Locations of Internal Server Components” on page 30
Customer-Replaceable Units
(CRUs)
System battery
DIMMs
PCIe card
PCIe riser
Power supply
Hard drive ller and hard drive
assembly
Air duct
Blower module
SP module
Internal cabling
Cable harness
I/O cable
“Replacing the System Battery (CRU)” on page 31
“Removing and Installing DIMMs (CRU)” on page 33
“Removing and Installing a PCIe Card (CRU)” on page 40
“Removing and Installing the PCIe Riser (CRU)” on page 42
“Removing and Installing a Power Supply (CRU)” on page 45
“Removing and Installing a Hard Drive Filler and Hard Drive Assembly
(CRU)” on page 48
“Removing and Installing the Air Duct (CRU)” on page 52
“Replacing a Blower Module (CRU)” on page 54
“Removing and Installing the SP Module (CRU)” on page 59
“Sun Fire X2270 M2 Server Internal Cabling” on page 61
“Replacing the SATA Cable Harness (CRU)” on page 62
“Replacing the Front I/O Cable (CRU)” on page 63
Field-Replaceable Units (FRUs)
2
See Also
Component Replacement Procedures and Topic
29
