Component Designation
HD backplane FRU
Front I/O board FRU
DIMM CRU
Power Supply 600 W CRU
Hard drive CRU
Solid-state drive CRU
Slide rail kit CRU
Tool-less slide rail kit CRU
Cable management arm CRU
Service processor module CRU
SATA cable CRU
Blower assembly CRU
Battery (CR2032) CRU
Front I/O cable kit CRU
Riser card, PCIe x16 slot CRU
Next:“Tools and Supplies Needed” on page 20
Tools and Supplies Needed
You need the following tools and supplies to perform Sun Fire X2270 M2 Server maintenance
procedures:
■
#2 Phillips screwdriver (6 inches)
■
Small at-blade screwdriver
■
Antistatic wrist strap
■
Portable light source
■
Antistatic brush, canned air, or a vacuum cleaner (to remove dust and debris)
■
Alcohol pads (for CPU replacement by service personnel only)
Next:
“How to Prepare for Service” on page 21
Tools and Supplies Needed
Sun Fire X2270 M2 Server Service Manual • January, 2012, –1220
