Orban 5750 Technical Manual Installation 2-23
B) FM + Delay
C) Monitor
D) HD
E) HD + Delay
F) Analog In
G) Digital In 1
H) Digital in 2
I) AoIP In 1
J) AoIP In 2
K) Stream In
Use the up and down buttons to scroll thru the options and touch the source you would like to monitor.
For convenience (and your ears), the headphone LEVEL button is in the top right of your screen to jump back to the
level control to adjust. In the lower right corner is the BACK button which takes you back to the main screen.
The final button is the next button “>” which changes the meter display to show the HD/DAB metering. When in
that mode, the “>” button becomes “<” to switch back to the FM metering.
MAIN MENU
The third and final button on the meter screen takes you to the MAIN MENU. This is where you can setup your 5750
and check on the status of the hardware.
INFO
Info is the diagnostic screens for the 5750. The following information can be found under the info tab
• Version
• Serial Number
• MAC Address
• IP, Subnet and Gateway addresses
• Hostname
• Temperature
• Fan Speed
