ORBCOMM OGi User Manual

OGi Modem - Hardware Guide
© ORBCOMM Proprietary 15 T401, Version .15
Pin
Name
I/O
Voltage
Description
9
GND
-
-
Ground
10
Reserved
-
-
Do not connect
11
DEBUG_RX
I
-
3.3 V logic levels
12
Reserved
-
-
Do not connect
13
DEBUG_TX
O
-
3.3 V logic levels
14
Reserved
-
-
Do not connect
15
MASTER_RESET
I
-
High impedance, active low
internal 10 kΩ pull-up, pull-
down with field effect
transistor.
16
Reserved
-
-
Do not connect
17
Reserved
-
-
Do not connect
18
GND
-
-
Ground
19, 20
Reserved
-
-
Do not connect
21
GND
-
-
Ground
22, 23
Reserved
-
-
Do not connect
24
MAIN_POWER
I
5.0 – 15.0 VDC
Input voltage
25
Reserved
-
-
Do not connect
26
GND
-
-
Ground
27
GND
-
-
Ground
28
Reserved
-
-
Do not connect
29
GND
-
-
Ground
30
1PPS
O
3.3 V logic level
Output
31…33
Reserved
-
-
Do not connect
34
GND
-
-
Ground
35
GND
-
-
Ground
36…39
Reserved
-
-
Do not connect
40
GND
-
-
Ground
41…49
Reserved
-
-
Do not connect
50
GND
-
-
Ground
51
Reserved
-
-
Do not connect
52
MAIN_POWER
I
5.0 – 15.0 VDC
Input voltage
3.2 RF Connector
Parameter
Value
Modem RF Connector
MMCX, female (jack) connector
Unpackaged Antenna RF
Connector
IPEX (U.FI) SMT receptacle
