APPENDIX B Remote Antenna Template
CAUTION Before drilling check the template against actual hardware for
dimensional accuracy. If it is not correct, DO NOT USE THIS
TEMPLATE.
CAUTION Cable management and connector strain relief MUST be
incorporated in the installation. Secure the cable no more than
15 cm from the antenna enclosure and at regular intervals along
its length as part of the installation to prevent cable wear and
eliminate strain on the connector. Damage to the connector
interface or cable may otherwise result leading to hardware
failure.
