ORBCOMM OGi - Packaged Standard Antenna Height Dimensions

OGi Modem - Hardware Guide
T401, Version .15 22 © ORBCOMM Proprietary
3.10.2 Packaged Antenna - Standard
Figure 12 Packaged Antenna (Standard and Low Elevation) - Bottom View (mm)
Figure 13 Packaged Standard Antenna Height Dimensions (mm)
126.2±0.2
2 x 112.8
4 x 15.9
35.5±0.2
46.5±0.2
4 x 5.500
(HOLE)
2 x 72.4
25±0.3
