TECHNICAL MANUAL BLUE PAPER ORDU · OMX 202116 | ORBEA ORBEA | 17
EN
Rear axle measurements 12x165mm
Rear axle thread pitch DOUBLE LEAD “MAVIC SPEED RELEASE” 2P1.0
Rear axle thread length 15mm
Seatpost
CARBON AERO. ORDU SPECIFIC
XS-S/M: 330mm
M/L-XL: 370mm
Seatpost wedge INTEGRATED. ORDU SPECIFIC
Seatpost minimum insertion
XS: 100mm
S/M: 100mm
M/L: 110mm
XL: 110mm
Front post minimum insertion 40mm. All sizes
Front derailleur DOWNPULL. BRAZE-ON. REMOVABLE HANGER
Front derailleur angle 63º
Chainring size (1X)
MINIMUM 40T - MAXIMUM 56T
MAXIMUM OVAL 56T
Chainring size (2X)
Big chainring
SHIMANO/CAMPAGNOLO: MIN 50T - MAX 56T
SRAM: MIN 46T - MAX 56T
MAXIMUM BIG OVAL CHAINRING: 56T
Small chainring
MAXIMUM 46T
MAXIMUM SMALL OVAL CHAINRING: 46T
Cassette smallest sprocket size FROM 10T TO 14T
Minimum Q-factor 146mm
Maximum crank length 175mm
Rear derailleur hanger STANDARD AND DIRECT MOUNT
Drivetrain compatibility
(Only disc brake groupsets)
SHIMANO: ROAD 2x11 (Goupsets with TT brake and gear levers)
SRAM: ROAD 2x11, 2x12, 1x12 (Goupsets with TT brake and gear levers)
Blipbox juntion bracket (Etap) bolted to stem cover
CAMPAGNOLO: Campagnolo TT disc brake levers not available
TRP HD-T912 (brake only): It may be necessary to shorten the base handlebar
ends until the desired lever position is achieved
Material
Frame ORBEA CARBON OMX
Fork ORBEA CARBON OMX
Seatpost / frontpost
ORBEA CARBON OMX
Recommended use
TRIATHLON/TT
Available sizes
XS - S/M - M/L - XL
(S/M and M/L sizes share frame and fork. Seatpost and frontpost length changes)
Base handlebar AERO. ORDU SPECIFIC. 2 POSITIONS
#GTQ1TFWURGEKƂE2QUKVKQPU
(TQPVRQUVDTKFIG1TFWURGEKƂE
Adjustable in height, length and angle
Compatible extensions diameter 22.2mm
Front post adjustment range SEE SIZING SECTION
Fork
ORDU SPECIFIC
Integrated headtube
Hinge type headset
Fork rake 53mm
Fork sizes
5K\GURGEKƂEKPVGITCVGFJGCFVWDG
XS
S/M-M/L
XL
Headset 1" - 1-1/8" INTEGRATED. HINGE TYPE
Headset
bearings
UPPER: 1"
LOWER: 1-1/8"
Wheel size
Maximum tyre width 700C. 28”
UCI legal 700x28C (External diameter: 688mm)
Triathlon 700x30C (External diameter: 692mm)
Optimal aerodynamics
700x25C
Bottom bracket
PRESS FIT. BB386EVO
Bottom bracket shell width 86.5mm
Bottom bracket shell diameter 46mm
Front dropouts standard 12x100mm
Front axle measurements 12x119mm
Front axle thread pitch DOUBLE LEAD “MAVIC SPEED RELEASE” 2P1.0
Front axle thread length 13mm
Rear dropouts standard 12x142mm
05 TECHNICAL
SPECIFICATIONS
