INSTALLINGYOURTHERMOSTAT
Wire Installation for Heat Pump Systems
a. Loosen the screws on each terminal.
b. Insert jumper wire into the Y and W
terminals.
c. Insert each labeled wire into the matching
terminal and tighten the screws.
d. Wrap exposed areas of any unused wire
with electrical tape.
screw
labeled
wire
/"
9.5 mm
Note: Expose 3/8" of each wire for proper installation.
jump wire
To Next Page
