Specifications and Components
Chainsaw Model CS1500-092
Specifications and Components
WARNING: Using replacement parts other than those specified in this instruction
manual increases the risk of injury. Never use cutting attachments other than those
described in this manual. Serious or even fatal injuries could result if the wrong cutting
attachments are used.
REPLACEMENT COMPONENTS
40 CM
PART NUMBER
45 CM
PART NUMBER
Guide bar 160SDEA041 180SDEA041
Replacement Chain 573268 571039
Drive sprocket 570964 570964
Chain tensioning gear 570963 570963
SPECIFICATIONS 40 CM 45 CM
Voltage 230 VAC ~50 Hz 230 VAC ~50 Hz
Amperage 10.4 Amps 10.4 Amps
Power 2400 Watts 2400 Watts
Oil capacity 140 ml (4.7 oz) 140 ml (4.7 oz)
Bar and chain oil Oregon
®
brand Oregon
®
brand
Dry weight assembled 5.9 kg (12.9 lb) 6 kg (13.1 lb)
Dry weight without bar and chain 5 kg (11 lb) 5 kg (11 lb)
Guaranteed sound power level Lwa (1) (2) 110 dBA (Kwa=2.5 dBA) 110 dBA (Kwa=2.5 dBA)
Vibration 4.35 m/s
2
(K=1.5m/s
2
) 4.35 m/s
2
(K=1.5m/s
2
)
Max bar length 400 mm (16 inches) 450 mm (18 inches)
Effective cutting length 37 cm (15 inches) 43 cm (17 inches)
Chain pitch 3/8" Low Profile
™
3/8" Low Profile
™
Chain gauge .050 in .050 in
Drive sprocket teeth 6 6
No load chain speed 14.7 m/s (48.1 ft/s) 14.7 m/s (48.1 ft/s)
() According to Noise directive //EC, amended by //EC
() Measured according to EN -:+A: and EN--:+A:;
Sound Pressure level, LpA, is dB(A) with an uncertainty KpA of .dB(A)
