Guide Bar
Mechanical Timber Harvesting Handbook 58
.404" Pitch Guide Bar Mounts
L148
1
2
2
3
3
Drive sprocket
tooth count:
11, 12, 13
Dimensions:

.394" (10
mm) x
3.338"

.555" x
.404"

.435"
L205
1
2
1
Drive sprocket
tooth count:
11, 12, 13
Dimensions:

.555" x
.404"

.640"
M104
1
2
2
Drive sprocket
tooth count:
9, 10, 11
Dimensions:

.394" (10
mm) x
3.338"

.555" x
.404"
M226
1
2
2
M226 .404”
Drive sprocket
tooth count:
9, 10, 11
Dimensions:

.570" x
3.914"

.311"
