18
08.03/WE
ORGAPACK OR-H 20 A
1 TECHNICAL DATA
TABLE OF CONTENTS
Weight 9.7 kg (21.3 lbs)
Dimensions Length 310 mm (12.2")
Width 105 mm (4.1")
Height 240 mm (9.5")
Tension force Up to approx. 4000 N
Tension speed 115 mm/s (4.53“/s)
Air pressure Maximum 6 bar static
Air consumption
– Tensioning 6 Nl/s
– Sealing 6 Nl
Air connection G
1
/
4
“ (
1
/
4
“ NPT)
Sealing Sealless notched joint
Emission sound pressure
levels, measurement
type A (EN ISO 11202) L
pA
76 dB (A)
Vibrations at handle
(EN ISO 8662-1) a
h,w
< 2,5 ms
-2
STEEL STRAP
Strap width 13, 16 mm (
1
/
2
",
5
/
8
")
Normal quality:
Strap thickness Up to 0.60 mm (.023")
Tensile strength Up to approx. 850 N/mm
2
(120'000 lbs/in
2
)
High strength quality:
Strap thickness Up to 0.50mm (.019")
Tensile strength Up to approx. 1100 N/mm
2
(157'000 lbs/in
2
)
Page
1 Technical data 18
2 General information 19
2.1 Information on environmental protection 19
3 Safety instructions 20
4 Description 21
4.1 Design 21
4.2 Function 21
5 Initial operation 22
5.1 Suspending the tool 22
5.2 Compressed-air connection 22
6 Operating instructions 23
6.1 Operating the tool 23
7 Preventive and corrective maintenance 25
7.1 Adjusting tensioning force/tensioning speed 25
7.2 Setting clearance between tension wheel and
tension plug 25
7.3 Setting the cut-off depth 25
7.4 Replacing tension wheel 26
7.5 Replacing the toothed plate 26
7.6 Replacing knife, die and die plate 27
7.7 Cleaning the tool 27
8 Parts list 28
Explosion drawing 30
9 Parts list compressed air motor 31
Explosion drawing 32
We take sole responsibility in declaring that the tool
OR-H 20 A, to which this declaration refers, is in full
accordance with the current requirements of the
guidelines laid down by the council on 22th June
1998 (98/37/EEC), „Machine Guidelines“.
According to norm:
EN 292-1, EN 292-2, EN 349, EN 983, EN 1050,
prEN 792-2
CH-8953 Dietikon, May 2001
Manager Manager
Sales & Marketing: Engineering:
R. Kieffer M. Binder
DECLARATION OF AGREEMENT
