Orgapack 100 Series - 8 Parts List; Explosion Drawing

28
08.03/WE
ORGAPACK OR-H 20 A
1 1173.940.002 Base plate 13 mm
incl. pos. 2–4 1
1 1173.950.005 Base plate 16 mm
incl. pos. 2–4 1
2 1820.020.193 Bushing 1
3 1820.030.347 Guide bolt 2
4 1921.308.400 Cylindric pin, ø 8 x 40 2
5 1173.500.004 Strap stop 1
* 6 1910.803.108 Cylinder screw, M 3 x 10 3
7 1820.010.160 Compression spring 7
8 1173.500.070 Ejector bolt bottom 4
9 1173.500.068 Cover plate 1
* 10 1911.703.087 Counter sunk screw, M 3 x 8 2
11 1173.500.079 Front plate 1
12 1921.404.141 Spiral pin, ø 4 x 14 2
* 13 1173.700.147 Die 13 mm 1
* 13 1173.700.148 Die 16 mm 1
14 1922.103.121 Ridget pin, ø 3 x 12 1
15 1910.606.162 Set screw, M 6 x 16 1
16 1173.500.026 Cutting wire 1
17 1820.020.181 Shim 1
* 18 1820.040.094 Toothed plate 1
* 19 1830.000.287 Safety wire 1
20 1173.500.066 Ejector 1
21 1173.940.001 Stop plate 13 mm 1
21 1173.950.004 Stop plate 16 mm 1
22 1820.030.409 Bolt 1
23 1911.905.102 Counter sunk screw, M 5 x 10 1
24 1820.030.346 Bolt 1
25 1820.020.239 Adjusting nut 1
26 1820.020.240 Stop ring 1
27 1820.030.378 Stop screw 1
28 1927.600.310 O-Ring, ø 3 x 1,5 1
29
30 1173.600.011 Housing right,
incl. pos. 31, 32, 40, 41 1
31 1937.312.203 Cylindric bearing, ø 12 x 20 1
32 1937.310.103 Cylindric bearing, ø 10 x 10 1
33
34
35
36
37
38
39
40 1173.500.077 Guide pin 2
41 1920.108.102 Retaining ring, ø 8 2
42
* 43 1173.540.003 Die plate 13 mm 1
* 43 1173.550.003 Die plate 16 mm 1
* 44 1910.803.088 Cylinder screw, M 3 x 8 4
When ordering please indicate part number and quantity Explosion drawing see page 30
* Recommended spare parts
Pos. Part no Part name Quantity
8 PARTS LIST 1831.002.002/1
Pos. Part no Part name Quantity
45 1173.500.012 Holder 1
46 1910.608.122 Set screw, M 8 x 12 2
47 1173.500.069 Ejector bolt top 3
48 1173.500.007 Angular lever 2
49 1935.510.200 Slide bearing, ø 10 x 20 2
50 1173.500.024 Link 2
51 1921.801.122 Roll pin, ø 2 x 12 2
52 1820.030.313 Bolt 2
53
54 1173.500.019 Pusher 1
55 1173.500.013 Guide rail right 1
56 1911.905.122 Counter sunk screw, M 5 x 12 4
57 1820.030.337 Bolt 2
58 1173.500.014 Guide rail left 1
59 1820.020.184 Roller 2
60 1820.030.310 Shoulder bolt 2
61 1820.010.153 Compression spring 1
62 1923.608.162 Rivet, ø 8 x 16 1
* 63 1173.540.007 Strap guide lever 13 mm 1
* 63 1173.550.007 Strap guide lever 16 mm 1
* 64 1911.008.202 Cylinder screw, M 8 x 20 3
* 65 1173.500.022 Cylinder screw 1
66
67 1173.600.012 Housing left 1
68 1911.008.308 Cylinder screw, M 8 x 30 2
69 1911.106.358 Cylinder screw, M 6 x 35 2
70
71
72 1820.010.152 Compression spring 1
73 1928.011.250 K-Ring, ø 125 1
74 1173.500.018 Piston 1
75 1917.906.388 Washer, M 6 3
76 1911.906.202 Counter sunk screw, M 6 x 20 3
77 1173.900.009 Cylinder 1
78 1820.100.029 Bushing 2
79
80 1910.408.062 Set screw, M 8 x 6 6
81 1919.606.072 Lock washer, M 6 4
82 1911.106.458 Cylinder screw, M 6 x 45 4
83 1173.500.076 Guide right 1
84 1911.906.102 Counter sunk screw, M 6 x 10 2
85 1911.906.122 Counter sunk screw, M 6 x 16 2
86 1173.500.075 Guide left 1
87
88 1173.500.015 Sealing block 1
89 1921.604.121 Spiral pin, ø 4 x 12 1
* 90 1173.500.061 Knife "A" 1
91 1921.403.121 Spiral pin, ø 3 x 12 1
92
93 1820.070.014 Collar packing 1
