29
08.03/WE
ORGAPACK OR-H 20 A
Pos. Part no Part name Quantity Pos. Part no Part name Quantity
94 1820.010.123 Compression spring 1
95 1820.030.308 Air release screw 1
96 1940.401.720 Silencer, G 1/4“ 1
97
98 1173.900.006 Gear housing, incl. pos. 99, 100 1
99 1937.312.163 Cylindric bearing, ø 12 x 16 1
100 1921.403.101 Spiral pin, ø 3 x 10 1
101 1820.010.213 Compression spring 1
102
103 1911.505.088 Hex screw, M 5 x 8 1
104 1933.722.200 Needle bearing, ø 22 x 20 1
105 1935.632.150 Thrust bearing, ø 32/54 x 1,5 1
106 1820.060.064 ZTA-Wheel 1
107 1820.060.080 ZTA-Pinion 1
108 1934.310.170 Thrust needel bearing,
ø 17/30 x 2,8 1
109 1934.450.200 Counter washer, ø 20/34,5 x 3 1
110
111 1933.908.080 Needle bushing, ø 8 x 8 1
112 1820.050.075 Blocking pawl 1
113 1820.010.010 Compression spring 1
114 1820.020.183 Bushing 1
115 1917.803.056 Washer, M 5 1
116 1911.005.108 Cylinder screw, M 5 x 10 3
117 1820.030.333 Rocker shaft 1
118 1821.080.004 Handle 1
119 1821.084.006 Lever green 1
120 1821.084.007 Lever yellow 1
121 1820.030.405 Shaft 1
122 1920.104.072 Retaining ring, ø 4 2
123
124 1921.305.120 Cylindric pin, ø 5 x 12 1
125 1820.010.144 Compression spring 1
126
127 1934.430.190 Counter washer, ø 19/31,5 x 0,8 1
*
128 1820.040.082 Tensioning wheel 1
129 1173.500.060 Tension shaft 1
130 1935.000.171 Internal ring, ø 8 x 12,5 1
131 1935.000.311 Internal ring, ø 12 x 12,5 1
132 1934.450.150 Counter washer, ø 15/27,5 x 3 1
133 1173.600.016 Bearing plate 1
134 1937.310.203 Cylindric bearing, ø 10 x 20 1
135 1934.015.120 Needle bushing, ø 15 x 12 1
136 1911.005.308 Cylinder screw, M 5 x 30 2
137 1173.540.002 Strap guide 13 mm 1
137 1173.550.002 Strap guide 16 mm 1
138 1820.020.145 Bushing 2
139 1173.500.056 Pawl lever 1
140 1173.900.002 Bearing lid 1
141 1934.012.120 Needle bearing, ø 12 x 12 1
142 1911.905.162 Counter sunk screw, M 5 x 16 2
143 1921.306.240 Cylindric pin, ø 6 x 24 1
144
*
145 1173.900.014 Hose 1
146 1941.101.040 Fitting, G 1/4“ 1
147 1941.210.720 Gasket, G 1/4“ 5
148 1940.122.720 Angular fitting, G 1/4“ 1
149 1941.112.720 L-Fitting, G 1/4“ 1
150 1940.070.723 One way restrictor, G 1/4“ 1
151 1941.102.720 Fitting, G 1/4“ 1
152 1941.102.722 Hollow screw, G 1/4“ 1
153
154 1940.311.721 Air plug, G 1/4“ 1
155
156
157 1890.200.022 Locking screw 2
158 1890.200.028 O - Ring, ø 15,3 x 2,4 2
159 1820.010.175 Compression spring 2
160 1820.100.028 Tappet 2
161 1927.600.610 O-Ring, ø 6 x 1,5 4
162 1890.311.030 O-Ring, ø 5,3 x 2,4 2
163 1173.900.008 Suspension bracket 1
163 1173.600.020 Suspension bracket universal 1
164 1911.006.168 Cylinder screw, M 6 x 16 2
165 1919.605.062 Lock washer, M 5 3
166 1911.005.128 Cylinder screw, M 5 x 12 3
167
168
169
170
171
172 1933.722.162 Needle bushing, ø 22 x 16 1
173 1173.900.013 Flange 1
174
175
176
177
178 1895.312.003 Key 1
179 1894.332.000 Compressed air motor
LZB 22 A 008-50 1
179 1894.352.000 Compressed air motor
LZB 22 A 022-56 (1)
180
181
182 1173.900.017 Pawl 1
183
184 1820.090.068 Oil plate 1
185
186
187
188
189
190
191 1820.090.198 Name tag 1
192 1820.090.172 Name tag “Made in Switzerland“ 1
Variation USA/CAN
154 1820.100.019 Air connector, 1/4“-18 NPT 1
181 1820.100.017 Transition connection,
G 1/4“ x 1/4“ NPT 1
