Installation
General instructions
IG-136-EN version 10; 23/06/2016
33
cgm.3 system
Fully SF6 gas insulated medium voltage switchgear up to 40.5 kV in accordance with IEC Standards
4.9 Assembly and connection of measuring transformers in cgm.3-m
The medium voltage and current transformers are housed
in tracks installed in the cgm.3-m metering modular cubicle
by Ormazabal.
The layout and connection of these transformers
(maximum three voltage transformers and three current
transformers per metering cubicle) will correspond to the
order configuration and the type of transformers to be
installed.
For further information on the installation and
connection of cgm.3-m metering transformers
by Ormazabal, check the operations manual
MO-082 “Installation of transformers and
busbars in metering cubicles”.
