digiBASE-E™ High-Performance Power-over-Ethernet Multichannel Analyzer / PMT Base for Scintillation Detectors
iv
3.1.1. Amplifier....................................................... 17
3.1.2. Amplifier 2 ..................................................... 18
3.1.3. ADC .......................................................... 18
3.1.3.1. Gate ................................................... 19
3.1.4. Stabilizer....................................................... 20
3.1.5. High Voltage ................................................... 21
3.1.6. About ......................................................... 21
3.1.7. Status ......................................................... 22
3.1.8. Presets......................................................... 22
3.2. Troubleshooting ....................................................... 23
3.2.1. Connection Failed / Socket Error (Incompatible Static IP Address)......... 23
3.2.2. Cannot Communicate with MAESTRO or ScintiVision-32 ............... 26
4. SPECIFICATIONS......................................................... 27
4.1. Performance .......................................................... 27
4.2. Inputs ............................................................... 28
4.3. Use with Lanthanum Chloride and Lanthanum Bromide Detectors............... 28
4.4. Computer Controls and Indicators......................................... 28
4.5. Electrical, Mechanical, and Environmental.................................. 29
4.6. Feature Mask Bits ..................................................... 29
5. FIRMWARE COMMANDS AND RESPONSES ................................. 35
5.1. C
ONNECTIONS ......................................................... 35
5.1.1. Command Records ............................................... 35
5.1.2. Percent Response Records ......................................... 36
5.1.3. Dollar Response Records .......................................... 38
5.1.4. Command Catalog ............................................... 38
APPENDIX A. SETTING THE COARSE GAIN JUMPER ........................... 61
APPENDIX B. LIST MODE ................................................... 63
B.1. List Mode Data ....................................................... 63
INDEX..................................................................... 65
