4. SPECIFICATIONS
29
Detector Spectra (A35-B32). Use the A11-B32 CONNECTIONS Programmer’s Toolkit for creating
custom software.
4.5. Electrical, Mechanical, and Environmental
Dimensions 2.5 in. (6.35 cm) diameter × 4.7 in. (11.94 cm) length.
Weight
Net 0.79 lbs. (0.36 kg).
Shipping ~5 lbs (2.27 kg).
Power Requirement #3 watts from PoE.
Ambient Operating Environment !10 to +60°C at 0–80%; non-condensing humidity.
NOTE The digiBASE-E will operate at !10°C, however, at power-on it should be at least 0°C
for proper startup.
CE Conforms to CE standards for radiated and conducted emissions, susceptibility and low-
voltage power directives.
Synchronous Operation Up to 12 digiBASE-Es can be daisy chained with one unit assigned
the SyncMaster gate mode (SET_GATE 7) and all slaves assigned the Sync gate mode
(SET_GATE 6) for time correlation of #100 ms between all units.
4.6. Feature Mask Bits
The following table describes the feature bits from the SHOW_FEATURES command discussed
on page 50. If the feature is supported in the digiBASE-E, the bit is set to 1; if the feature is not
supported, the bit is 0.
Bit Meaning
0 Software-selectable conversion gain
1 Software-selectable coarse gain
2 Software-selectable fine gain
3 Gain stabilizer
4 Zero stabilizer
5 PHA mode functions available
6 MCS mode functions available
7 List mode functions available
