digiBASE-E™ High-Performance Power-over-Ethernet Multichannel Analyzer / PMT Base for Scintillation Detectors
Bit Meaning
30
8 Sample mode functions available
9 Digital Offset (e.g., 920)
10 Software-selectable analog offset
11 HV power supply
12 Enhanced HV (SET_HV, SET/SHOW_HV_POL, SHOW_HV_ACT)
13 Software-selectable HV range (ENA_NAI, DIS_NAI)
14 Auto PZ (START_PZ_AUTO)
15 Software-selectable manual PZ (SET/SHOW_PZ)
16 Battery-backed, real-time clock (SHOW_DATE/TIME, SHOW_DATE/TIME_START)
17 Sample changer support (SET/SHOW_OUTPUT, SHOW_INPUT)
18 One-button acquisition (ENA/DIS/SHOW_TRIG_SPEC, MOVE)
19 Nomadic (likely to move between opens)
20 Local app data (SET_DATA_APP, SHOW_DATA_APP)
21 Software-retrievable serial number
22 Power management commands
23 Battery status support (SHOW_STAT_BATT)
24 Software-selectable AMP polarity (SET/SHOW_GAIN_POLAR)
25 Support for flattop optimization (ENA/DIS_OPTI)
26 Stoppable AutoPZ (STOP_PZ_AUTO)
27 Network support (e.g., DSPEC)
28 Multi-drop serial support (e.g., MicroNOMAD)
29 Software-selectable DPM address (SET_DPM_ADDR)
30 Multiple devices (e.g., 919)
31 Software-selectable ADC gate mode (SET_GATE...)
Beginning of 2nd word
32 Software-downloadable firmware
33 Time histogramming functions available (e.g., 9308)
34 Software-selectable lower level discriminator
35 Software-selectable upper level discriminator
36 MCS-mode SCA input available
37 MCS-mode positive TTL input available
38 MCS-mode fast-negative NIM input available
39 MCS-mode discriminator input available
40 Software-switchable MCS-mode discriminator edge
41 Software-programmable MCS-mode discriminator level
42 Software-programmable SCA upper and lower thresholds
