5. FIRMWARE COMMANDS AND RESPONSES
51
Responses:
$C00000087<CR> Gain channel has not been set.
$C00002089<CR> Gain channel is channel 2 (lowest possible channel).
$C00250094<CR> Gain channel is channel 250.
SHOW_GAIN_CONVERSION
This command returns the conversion gain for the digiBASE-E, which can be 256, 512,
1024, or 2048 channels.
Responses:
$C02048101<CR> Conversion gain reported as 2048 channels.
SHOW_GAIN_FINE
Returns the current fine gain setting (not the coarse gain setting; see Appendix A). See
SET_GAIN_FINE.
Sample Response:
GAIN_FINE 000000.44439999 Fine gain is set to 04444.
SHOW_GAIN_POLARITY
Returns the polarity of the amplifier input as $F records.
Responses:
$IPOS<CR> Always positive in digiBASE-E.
SHOW_GAIN_STABILIZATION
Reports the state of gain peak stabilization. See also ENABLE_GAIN_STABILIZATION
and DISABLE_GAIN_STABILIZATION.
Responses:
$IT<CR> Gain stabilization is currently enabled.
$IF<CR> Gain stabilization is currently disabled.
SHOW_GAIN_WIDTH
Reports the current width for the stabilizer gain peak. See also SET_GAIN_WIDTH,
SET_GAIN_CHANNEL, and SHOW_GAIN_CHANNEL.
Responses:
$C00001088<CR> Gain width has not been set.
$C00003089<CR> Gain width is 3 channels (lowest possible width).
... ...
$C00256100<CR> Gain width is 256 channels
