digiBASE-E™ High-Performance Power-over-Ethernet Multichannel Analyzer / PMT Base for Scintillation Detectors
7
This sync pulse is a time-stamp sync. Because each digiBASE-E uses its own internal clock, when operating
multiple digiBASE-Es together, they tend to diverge. The sync pulse is used to correct the divergence.
64
Second word
Data[31:30] = 1
Data[29:0] = Livetime[29:0]
External Sync Stamp (each 100 ms if generated from a digiBASE-E sync pulse)
7
Data[31:30] = 0
Data[29:0] = Realtime[12:0],Prescale[17:1]; note that these are two separate entities, not
a single number.
