Osaka F 200 - F Evaporator Control Parameters (Fans); P Compressor Protection Parameters; A Alarm Configuration Parameters; o Buzzer Outputs and Configuration Parameters

OSAKA - F 200 / F 300 / TSF 200 / TSF 300 / M3 - User Manual - V.2 - PAG. 11
32
d.dL
Display block in
defrosting.
oF = Displays actual
temperature.
on = Displays the last
measure
Lb = Displays "dEF"
defrosting and "PdF"
oF - on - Lb
Lb
“F” Evaporator Control Parameters (Fans)
Par.
Description
Range
Def.
Note
33
F.tn
Activation of the
evaporator fan
compressor off
oF ÷ 0.01 ÷
99.5
5.00
34
F.tF
Deactivation time
compressor evaporator
fan stop
oF ÷ 0.01 ÷
99.5
oF
35
F.FL
Maximum temperature
for blocking fan (PR2)
- 99.9 ÷ 999
°C/°F
2.0
36
F.LF
Minimum fan blocking
temperature (PR2)
- 99.9 ÷ 999
°C/°F
-99.9
37
F.dF
Fan differential lock
0 ÷ 30
°C/°F
1.0
38
F.FE
State fan during
defrost
oF – on
oF
39
F.Fd
Fan delay after defrost
oF ÷ 0.01 ÷
9.59 (min.sec)
÷ 99.5
(min.sec)
3.30
“P” Compressor Protection Parameters
Par.
Description
Range
Def.
Note
40
P.P1
delay to start
oF ÷ 0.01 ÷
99.5
oF
41
P.P2
Delay after stop or
minimum downtime
oF ÷ 0.01 ÷
99.5
oF
42
P.P3
Delay after the
consecutive starts
oF ÷ 0.01 ÷
99.5
oF
43
P.od
Delay compressor start
to energizing the
instrument.
oF ÷ 0.01 ÷
9.59 (min.sec)
÷ 99.5
(min.sec)
oF
“A” Alarm Configuration Parameters
Par.
Description
Range
Def.
Note
44
A.Ay
Temperature alarm
type:
1 = Absolute probe
"Pr1" with visualization
display (Hi - Lo)
2 = Relative probe
"Pr1" with visualization
display (Hi - Lo)
3 = Absolute probe
"Au" with visualization
display (Hi - Lo)
4 = Relative probe
"Au" with visualization
display (Hi - Lo)
5 = Absolute for "Pr1"
no display on display
6 = Relative to "Pr1"
without viewing display
7 = Absolute probe
"Au" display no display
8 = Relative probe
"Au" no display on
display
1 / 2 / 3 / 4 / 5 /
6 / 7 / 8
1
45
A.HA
Set Point alarm for
high temperature
oF / - 99.9 ÷
999 °C/°F
oF
46
A.LA
Set Point alarm for low
temperature.
oF / - 99.9 ÷
999 °C/°F
oF
47
A.Ad
Differential
temperature alarm.
0 ÷ 30
°C/°F
1.0
48
A.At
Temperature alarm
delay
oF ÷ 0.01 ÷
9.59 (min.sec)
÷ 99.5
(min.sec)
oF
49
A.tA
Memory alarm.
Off-on
off
50
A.PA
Alarm on delay at start
oF ÷ 0.01 ÷
9.59 (h.min) ÷
99.5 (h.min)
2.00
51
A.dA
Delay of temperature
alarm after defrost,
defrost lock display.
oF ÷ 0.01 ÷
9.59 (h.min) ÷
99.5 (h.min)
0.05
52
A.oA
Open door alarm
delay.
oF ÷ 0.01 ÷
9.59 (min.sec)
÷ 99.5
(min.sec)
3.00
“o” - Buzzer Outputs and Configuration Parameters
Par.
Description
Range
Def.
Note
53
o.o1
OUT1 relay
configuration:
oF = no function
ot = Control
temperature
(compressor or
solenoid)
dF = Defrost
Fn = Fan
Au = Auxiliary
A /-tt = Alarm Silenced
AL /-L = Alarm not
muted
An /-n = preset alarm
on = output activated
when the device is
running
oF/ot/dF/
Fn/Au/At/
AL/An/ -t/ -L/ -
n/on
ot
54
o.o2
OUT2 relay
configuration: Similar
"o1".
oF/ot/dF/
Fn/Au/At/
AL/An/ -At/ -
AL/ -An/on
dF
55
o.o3
OUT3 relay
configuration: Similar
"o1".
*Only for F 300 / TSF
300 / M3
oF/ot/dF/
Fn/Au/At/
AL/An/ -At/ -
AL/ -An/on
Fn
56
o.bu
buzzer operation
oF = off
1 = only for alarm
2 = keypad sound only
3 = enabled alarm and
keyboard
*Only for F 300 / TSF
300 / M3
oF / 1 / 2 / 3
3
57
o.FO
Operating mode
auxiliary relay output
oF = No Function
1 = Check Out delayed
2 = Manual activation
of keyboard or In. Dig.
3 = cabinet light with
economy feature
(enabled with "SP"
standing with "SP2")
4 = internal light (door
stop)
oF / 1 / 2 / 3 / 4
oF
58
o.tu
Time relative to the
auxiliary output.
oF ÷ 0.01 ÷
9.59 (min.sec)
÷ 99.5
(min.sec)
oF
