OSAKA - F 200 / F 300 / TSF 200 / TSF 300 / M3 - User Manual - V.2 - PAG. 10
5 – PROGRAMMABLE PARAMETERS LIST
“S” parameters relative to the Set Point.
Par.
Description
Range
Def.
Note
1
S.LS
Minimum Limit Set
Point
-99.9 ÷ HS
-50.0
2
S.HS
Maximum Limit Set
Point
LS ÷ 999
99.9
3
S.SA
Active Set Point
1 ÷ 2
1
4
SP
Set Point 1
S.LS ÷S.HS
0.0
5
SP2
Set Point 2
S.LS ÷ S.HS
0.0
“i” Parameters for Digital Input and Probes
Par.
Description
Range
Def.
Note
6
i.SE
Type of probe
Pt - nt
nt
7
i.uP
Unit of measure and
resolution (decimal
point)
C0 = ° C with
resolution 1 °
F0 = ° F with resolution
1 °
C1 = ° C with 0.1 °
resolution
F1 = ° F with 0.1 °
resolution
C0 / F0 / C1 /
F1
C1
8
i.Ft
Measuring filter
oF ÷ 20.0
sec
2.0
9
i.C1
Calibration probe Pr1
(chamber)
-30 ÷ 30
°C/°F
0.0
10
i.C2
Calibration probe Pr2
(Evaporator)
-30 ÷ 30
°C/°F
0.0
11
i.C3
Calibration probe Pr3
(Auxiliary)
*Only for F 300 / TSF
300 / M3
-30 ÷ 30
°C/°F
0.0
12
i.CU
Visualization Offset
-30.0 ÷ 30.0
°C/°F
0.0
13
i.P2
Probe function Pr2
oF – EP – Au –
dG
EP
14
i.P3
Probe function Pr3
*Only for F 300 / TSF
300 / M3
oF – dG – Au –
Ep
dG
15
i.Fi
Digital Input function:
0 = No function
1= Start of defrost
2= End of defrost
3= Continuous Cycle
4= External Alarm
5= Open door with lock
fan
6= Open door with lock
fan and Cold / Heat
7= Activation Auxiliary
output
8= Active Set Point
Selection (SP-SP2)
9= External Alarm with
control output
deactivation
10= Start/Stop (Stand-
by)
11= Active Set Point
Selection (SP-SP2)
with inversion of
control (HC)
-11/-10 / -9 / -8
/ -7 / -6 / -5 / -4
/ -3 / -2 / -1 / 0 /
1 / 2 / 3 / 4 / 5 /
6 / 7 / 8 / 9 / 10
/11
5
16
i.ti
Actuate delay function
programmed on digital
input.
oF ÷ 0.01 ÷
9.59 (min.sec)
÷ 99.5
(min.sec)
0.05
17
i.dS
Variable shown on the
display:
P1 = Chamber Probe
Pr1
P2 = Evap. Probe Pr2
P3 = Auxiliary Probe
Pr3
SP= Active Set Point
oF = Display Off
P1 - P2 - P3 -
SP - oF
P1
“r” Parámetros de Regulación de Temperatura
Par.
Description
Range
Def.
Note
18
r.d
Differential
(Hysteresis) regulation
0 ÷ 30
°C/°F
2.0
19
r.t1
Activation of the
compressor relay if
defective sensors.
oF ÷ 0.01 ÷
9.59 (min.sec)
÷ 99.5
(min.sec)
oF
20
r.t2
Stop time of the
compressor relay if
defective sensors.
oF ÷ 0.01 ÷
9.59 (min.sec)
÷ 99.5
(min.sec)
oF
21
r.HC
Operating mode:
H = Heat (heat)
C = Cool (Cool)
H – C
C
22
r.tC
Continuous cycle
duration (Turbo frost).
oF ÷ 0.01 ÷
9.59 (h.min) ÷
99.5 (h.min)
oF
“d” parameters management "Defrost"
Par.
Description
Range
Def.
Note
23
d.dt
Type of defrost:
EL = Electric defrost or
compressor stop
In = hot gas defrost /
reverse cycle
no = compressor
maintains regulation
Et = thermostatic
evaporator defrost
EL / in / no / Et
EL
24
d.di
defrost interval
oF ÷ 0.01 ÷
9.59 (h.min) ÷
99.5 (h.min)
6.00
25
d.Sd
Delay of defrost at
start
(oF = Allows defrost at
start)
oF ÷ 0.01 ÷
9.59 (h.min) ÷
99.5 (h.min)
6.00
26
d.dE
Maximum duration of
defrost
oF ÷ 0.01 ÷
9.59 (min.sec)
÷ 99.5
(min.sec)
30.0
27
d.tE
Defrost end
temperature
- 99.9 ÷ 999
°C/°F
8.0
28
d.tS
Activation temperature
defrost
- 99.9 ÷ 999
°C/°F
2.0
29
d.dC
Trigger Mode
rt = a whole time
intervals
ct = time interval for
compressor operation
cS = Defrost at each
compressor stop
St = Automatic Defrost
Evaporator
Temperature (d.tS)
dd = Defrost a dynamic
range
rt / ct / cS / St /
dd
rt
30
d.dd
Defrost in dynamic
range
0 ÷ 100
0
31
d.td
Compressor delay
after defrost (drip)
oF ÷ 0.01 ÷
9.59 (min.sec)
÷ 99.5
(min.secx10)
2.00
