PAGE 15 10115208
OSD2254EP Operator Manual
2.2.8 LED INDICATORS
FIGURE 10: PORT/LED
TABLE 4: LED FUNCTION
No
Function
LED Colour Function
On
Blink
Off
Green
Gr/Am
Amber
Power
-
No Power
Power
-
-
Ring/Bus
Initial
Non-Ring
Ring
-
-
-
Activity
No Activity
1G/100M/10Mbps
-
-
PoE
-
No Load
PoE Load
Detected
-
-
Link
-
No Link
-
-
On
Fiber Link
Activity
No Link
1Gbps
-
100Mbps
Power
Supply 1
-
Not
Connected
Power On
-
-
Power
Supply 2
-
Not
Connected
Power On
-
-
