OSD2254EP Operator Manual
2.4.2 COMMAND LINE FUNCTIONS
There are a number of command line functions that enables the user to obtain running
information of a single OSD2254EP unit or the complete topology of the ring/bus network.
This section explains the command lines and its functions.
When the terminal emulation program is operating, connect the USB cable to any one of the
OSD2254EP units on the ring/bus network – or alternatively, the OSD2254EP unit which the
user wishes to interrogate. Note: A message will be displayed on the terminal emulation
program when the unit is powered after USB connection. This message will not open when
the unit is switched on while plugging in the USB cable, however the command lines are
functional.
The following table outlines the user available command line commands and their functions
TABLE 7: TERMINAL COMMAND LINES
TERMINAL
COMMAND
LINE
SPECIFICATION
FUNCTION
FIGURE
?
Help
Lists all CLI commands including
input format information
-
vc
Version Check
Displays the current software
version and revision installed on the
unit
Figure 18
fd
Factory Default
Reset configuration to factory
default
Figure 19
ipconfig
IP Configuration
Configure the IP address
Figure 20
tc
Topology Check
Displays the topology status of the
established ring/bus
Figure 21
nc
Node Check
Gets running status of the node for
given MAC address
Figure 23
lnc
Local Node Check
Gets running status of the local
node
Figure 24
fbe
Float Backup
Enable
Enable float backup function for all
nodes in a Ring/Bus
Figure 25
fbd
Float Backup
Disable
Disable float backup function for all
nodes in a ring/bus
Figure 29
node_ip_set
Node IP Set
Setup IP of the node with given
MAC address
Figure 32
node_all_set
Node All Set
Setup IP for all nodes on a ring/bus
Figure 33
reboot
Reboot
Reboot the device in the network
Figure 34
config_snmp
Configure SNMP
Change to SNMP sub menu
Figure 35
portctrl
Port Control
Enables/Disables all ports
Figure 37
portsecurity
Port Security
Change to Port Security
configuration sub menu
Figure 38
