Ossur i-limb hand Series User Manual

24 of 27 25 of 27
7.2 Technical Information
7.3 i-limb
®
hand Information
7.4 Component Compatibility
Please refer to www.touchbionics.com/downloads/document-library for Electro Magnetic Compatibility (EMC) and Electrical
Information for i-limb
®
products.
7.5 Warranty
Refer to www.touchbionics.com/downloads/document-library to review warranty information.
i-limb
®
hand
Voltage range 6 -8.4 V
Max. Current 6 A
Battery Capacity Rechargeable lithium polymer 7.4 V (nominal); 2,000 mAh capacity;
1,300 mAh capacity
Max hand load limit (static limit) 40 kg/88 lbs (Extra Small)
90 kg/198 lbs (Small/Medium/Large)
Finger Carry Load (static limit) 20 kg/44 lbs (Extra Small)
32 kg/71 Ibs (Small/Medium/Large)
Time from full open to full close 0.8 seconds
Device Weight
(quantum and revolution)
Note: Titanium digits add an ad-
ditional 30g/0.07lbs per hand
Extra Small Small Medium/Large
QWD 472g/1.04lbs 512g/1.13lbs 528g/1.16lbs
WD 432g/0.95lbs 472g/1.04lbs 488g/1.08lbs
Flexion 572g/1.26lbs 612g/1.35lbs 628g/1.38lbs
Friction 467g/1.03lbs 507g/1.12lbs 523g/1.15lbs
Device Weight
(ultra and access)
Note: Titanium digits add an ad-
ditional 30g/0.07lbs per hand
Extra Small Small Medium/Large
QWD 432g/0.95lbs 468g/1.03lbs 478g/1.05lbs
WD 392g/0.86lbs 428g/0.94lbs 438g/0.97lbs
Flexion 532g/1.17lbs 568g/1.25lbs 578g/1.27lbs
Friction 427g/0.94lbs 463g/1.02lbs 473g/1.04lbs
Hazardous Area Classification
The i-limb hand is not intended for use outside the boundaries of the environments listed below.
The user of the i-limb hand should assure that it is not used, transported or stored in such environments.
Condition Level
Maximum temperature +70˚c
Minimum temperature -40˚c
Hazardous Area Classification Non Hazardous
IP rating IP22
