26
OTICON AGIL FITTING GUIDE
27
Short Vents Long Vents
Micro Moulds use tube-shaped vents, as in traditional ear
Moulds, but the length is shorter than standard vents. There-
fore, the Micro Mould vent effect is much larger than its actual
diameter. Genie prescribes the vent size, when Micro Mould is
selected.
Check the Micro Mould vent size under Acoustics in Fitting
step. For further information about selecting vent sizes and
effective vent sizes please refer to the Genie helpfiles under
Acoustics.
Micro Mould Actual vent size (mm)
X-Large >2.4
Large 2.4
Medium 1.4
Small 0.8
No Vent 0
Canal RITE Moulds use tube-shaped vents just like Micro Moulds.
However, the vent is a little longer. Still, the canal’s vent effect
is larger than its actual diameter. Genie prescribes the vent
size (from X Large to No Vent) when Micro Mould is selected.
To reflect the actual diameter select the vent size for long
vents, e.g. Large (long).
Micro Mould Actual vent size (mm)
X-Large >2.4
Large 2.4
Medium 1.4
Small 0.8
No Vent 0
Attaching the Micro Mould
When fitting Oticon Agil RITE hearing devices with Micro
Moulds follow the instructions below:
Find the correct Receiver unit length and attach it to the
instrument (see Selecting Receiver Unit Length).
1. Carefully insert the Receiver into the Micro Mould and
push until you hear/feel a click.
2. When inserting the Receiver into a
modified Micro Mould
with a longer canal, use the Mould tool to snap the
Receiver more deeply into the Mould, as pictured.
3. The Mould can rotate axially to ensure maximum comfort.
Before placing the Mould in the ear, turn the Mould until
the up indicator points upwards.
