otometrics AURICAL Aud - Connector Warning Notes

Standards and safety-related issues relating to HI-PRO2 are comprised by the AURICALAud symbols, standards and warning
notes.
See Definition of symbols ► 34, Connector warning notes ► 35 and General warning notes ► 36.
19.1 Connector warning notes
Warning• Never mix connections between the two types of connectors shown below:
Direct connectors
• All connectors within the red frame are connected directly to patient transducers.
Fig. 1 Sockets with direct connections to patient transducers - AURICAL Aud connection panel
Isolated connectors
• All connectors within the red frame are isolated from patient transducers.
Note • The safety standards listed in Technical specifications ► 20 do not apply to the isolated connectors used in
the AURICALAud audiometer.
Fig. 2 Connectors isolated from patient transducers - AURICAL Aud connection panel
Otometrics - AURICAL Aud
35
19 Warning notes
