10
range. An electronic unit protects the battery from being overcharged. The power supply and bat
tery charger will heat up during the charging process.
INFORMATION
Battery life for a fully charged battery is:
Up to 96 hours in normal mode.
Up to 4 hours in bicycling mode.
The capacity of the battery decreases over the course of the product's operational life and with
the number of charging processes performed.
►
Replace the battery when battery life becomes noticeably reduced or when the battery
replacement signal is emitted.
The charging process and battery status are indicated by signals on the prosthetic knee joint
(light, sound, vibration) and battery charger (light) (see fig.5). The brightness of the light signals
adjusts to the ambient light. The signals are listed in the following table.
Notification Vibration signal Light signal Audible signal
Product activation
(when battery is inser
ted)
1x vibration impulse LED 3 lights up briefly, all
LEDs light up briefly
1 x signal tone, rising
Connecting battery
charger, charging bat
tery
1x vibration impulse LEDs light up, rising, during
the charging process: 1, 2, 3,
4, 5
1 x signal tone, rising
Disconnecting battery
charger, when battery is
fully charged
1x vibration impulse All LEDs light up for approx. 5
sec
1 x signal tone, short
Disconnecting battery
charger, when battery
not fully charged
1x vibration impulse LEDs 1, 2 light up for approx.5
seconds
1 x signal tone, short
Charging error (pros
thetic knee joint is not
charging)
If the battery is not
defective, several short
vibration signals
LEDs 1, 3, 5 light up for sever
al seconds
Signal tone, continu
ous
Battery defective or not
installed or reset to
factory default settings
– LED 3 lights up briefly, all
LEDs flash for several seconds
1 x signal tone, rising
1 x signal tone, siren
3 x signal tone, short
Battery capacity low 3 x vibration signal,
short
LEDs light up for several
seconds: 1, 3, 5 alternating
with 2, 4
3 x signal tone, short
Battery drained, switch
ing to safety mode
6 x vibration signal,
short
LEDs light up for several
seconds: 1, 3, 5 alternating
with 2, 4
6 x signal tone, short
Battery replacement
required
– LEDs light up, alternately
bright then dimmed
6xsignal tone, high
and short, 1xsignal
tone, low and short
Assembling the battery charger
> Required materials:
4G497 charging unit, 757L16* power supply
► Connect the charging unit to the power supply (see fig.6).
Charging the battery
1) Plug the battery charger plug into the outlet.
2) Carefully insert the charging plug into the charging receptacle on the prosthetic knee joint
(see fig.7).
3) If the device signals a charging fault, disconnect and then reconnect the charging plug.
