Otto Bock 3E80 - Preparation for Use; Charging the Battery

9
Fig. Item Quantity Designation Reference number
1 2 1 Universal power supply 757L16*
1 3 1 Charging unit 4G497
1 4 1 Adjustment wrench 710H10=2x3
Single-component pack, consisting of: 4G520
5 1 Lithium-ion battery –1
6 4 Battery mounting screws 501S84=M3x8
Single-component pack, consisting of: 4G513=SET
1 7 3 Front inlay –
5 Preparation for use
CAUTION
Incorrect alignment, assembly or adjustment
Risk of injury due to change in or loss of functionality
►
Assembly, adjustment and maintenance operations may only be completed by qualified per
sonnel.
►
Observe the alignment, assembly and adjustment instructions.
CAUTION
Use of talcum
Risk of injury, damage to the product due to lack of lubrication
►
Do not use talcum on the product or other prosthesis components.
CAUTION
Incorrect mounting of the tube
Risk of injury due to breakage of load-bearing components
►
Slide the tube all the way to the stop in the intended prosthetic component when mounting.
5.1 Charging the battery
CAUTION
Connecting the battery charger while a battery is not inserted
Fall due to prosthetic knee joint being automatically reset to factory settings
►
Only connect the battery charger to the prosthetic knee joint when the battery is inserted.
CAUTION
Using the prosthesis during the charging process
Fall due to connected charging cable
►
Take the prosthesis off before charging the battery.
►
Disconnect the prosthesis from the battery charger before putting it on.
INFORMATION
The battery is not fully charged upon delivery. The battery must be charged before the product is
used for the first time.
Ottobock recommends charging the prosthetic knee joint daily overnight. The charging process
can last up to 3hours and may only be performed within the prescribed charging temperature
