Otto Bock A 200 - 17 Technical Data of the Battery Charger

37
17 Technical Data of the Battery Charger
Automatic battery charger with computer-controlled characteristic curve for 24 V sulfuric acid batteries.
Power requirements: 230 V AC
Mains frequency: 50 Hz
Protection class: II, insulated twice
Charging connection: 24 VDC
Nominal charging current: max. 5A programmable
Protective system: IP 54
Weight: approx. 1 kg
Dimensions (WxHxD) (175 x 140 x 59) mm
