Delivery
Upon delivery by the dealer the A200 is ready for use. All settings have been made in accordance with the indi-
cations on the order form or are made directly on site by the dealer. Thus, the A200 is adapted to the personal
requirements of the individual.
Before using the wheelchair, all components of the standard equipment must be checked for completeness.
(Fig. 8).
1. Backrest
2. Armrest
3. Joystick & control unit
4. Seat cushion
5. Footrest
6. Motor with brake release and
r
ear wheel
7. Anti-tippers
The functions of the individual components must be checked according to the instructions in sections "Disas-
sembling the A200 Power Wheelchair", "Adjustment Possibilities", and "Putting into Operation". Should any
problems arise please refer to section "Status and Error Analysis". The tool kit, which is optionally available,
contains one set of Allen wrenches, sizes 3 mm, 4 mm, 5 mm, and 6 mm, and one open-end 13 mm spanner.
8 Adjustment Possibilities
The seat height and seat position of the A200 may only be adjusted or changed by the dealer.
All other settings such as: seat and back angle, armrest height and lower leg length, as well as the removal of
the footrests and armrest can be done by the user with the tool kit, which is optionally available.
Disassembly of the A200 power wheelchair can be easily done by an attendant. (Refer to section 6: Transport
and Storage)
8.1 Back
The back can be adjusted to four different angle positions by pulling the release strap which is located at the
base of the back. Once the back is in the desired position, release the strap to engage the locks.
Figure 9
Figure 8
1
2
3
4
5
7
6
