Outback Power Systems FLEXMAX 80 User Manual

38
PB
In the Low Batt Disconnect screen, press the <VOLT> soft
key to adjust the battery voltage disconnects
set point.
Press either the < - > or the < + > soft key to adjust the
disconnect voltage. Press the <ReCon> soft key to open
the RE-CONNECT VOLTS screen.
Press either the < - > or the < + > soft key to adjust the
RE-CONNECT VOLTS value. The AUX Output activates
when the voltage goes above this setting after the timer
has counted back to zero. Press the <BACK> soft key
to return to the Low Batt Disconnect screen. Press the
<DisV> soft key to return to the Disconnect Volts screen.
AUX MODE
Low Batt Disconnect
EXIT TIME VOLT
DISCONNECT VOLTS
< 13.6
BACK - + ReCon
RE-CONNECT VOLTS
> 14.4
BACK - + DisV
